Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-61
Figure 2-11. Cable Preparation for 219N Connector
* Registered Trademark of Thomas & Betts Corporation
Crimp KS-15712, L20 outer shield using
Inner foil shield should be removed from this area.
Cover the 219N Connector several times with tape.
Slide outer shell over 219N Connector and secure with screw.
solder slug is all that is required.
slug) of the 219N Connector. Do not add any additional solder, the
Apply soldering iron on bottom of barrel (opposite side of solder
Terminal of the 219N Connector should slide
Make sure center conductor is visible in barrel of 219 Connector.
Soldering of the 219N Connector must be done after the 219N
Connector has been assembled and crimped.
crimp tool or equivalent.
over cable dielectric but under braid
Solder slug
Fan braided shield and foil slightly
KS-15712, L20 Outer shield
following figure:
Slide the KS-15712, L20 over the 734A Cable as shown in the
Center conductor to be tinned.
(Leave the braided shield)
Prepare the 734A Cable as shown in the following figure:
Thomas & Betts*
STEP 8:
STEP 2:
STEP 1:
1/8"
7/16" 1/16"
STEP 7:
STEP 6:
STEP 5:
STEP 4:
WT-414
Slide outer shield over braid and terminal of 219 Connector as
Outer shield
shown in the following figure:
STEP 3:
Cable dielectric
To Next Page
