363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-43
Notes:
* TBOS cables have shipped with various wire color assignments. These cables are correct
for G348 and G349 cables with manufacturing dates of 5/92 or later. Cables with colors
assignments varying from the above table should be continuity tested using the lead designa-
tion and connector terminal number to determine proper wire color assignment.
1. The TBOS telemetry cable is 26 gauge.
Note
:
The TL1/X.25 interface cable is 26 gauge.
Table 2-10. TBOS Serial Telemetry Connections
Name Design. Conn. Term Color
Transmitted True Data
To Telem. Equip.
TDP
P53
2 O-W or BR-W*
Transmitted Inverted Data
To Telem. Equip.
TDN 7 W-O or W-BR*
Received True Data
To Telem. Equip
RDP 1 BL-W or G-W*
Received Inverted Data
To Telem. Equip.
RDN 6 W-BL or W-G*
Table 2-11. TL1/X.25 Interface Connections
Name Design. Conn. Term Color
Transmitted Data TDA J45 2 BL-W
Received Data RDA 3 O-W
Request to Send RTS 4 G-W
Clear to Send CTS 5 BR-W
Data Set/DCE Ready DSR 6 S-W
Signal Ground GRD 7 BL-R
Received Line Signal Detector CDC 8 O-R
Transmitter Signal Element Timing TCK 15 W-BL
Receiver Signal Element Timing RCK 17 W-G
Data Terminal/DTE Ready DTR 20 R-BL
Ring Indicator RID 22 R-G
