363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-33
Notes
:
1. Each group listed includes all the DS1 cables for one function group.
2. The length (30 to 440 feet) of Groups 306, 312, and 318 is specified by the customer. The
length (30 to 655 feet) of Groups 303, 309, and 315 is specified by the customer.
3. 613C type cable is 22 gauge (maximum length is 655 feet).
4. 1249C type cable is 26 gauge (maximum length is 440 feet).
5. Cables are terminated in 963P-16 or 963TR-16 connectors at the DDM-2000 OC-3 end
and unterminated at the other end for wire-wrap installation.
Table 2-1. DS1 Cable Assemblies
Description
ED-8C724-20
Group (Note 1)
Cable Length
(ft.) (Note 2)
Cable
Ty pe
(Note 3)
DDM-2000
Backplane
Connections
ED-8C724-30, G1 Shelf
TX and RX: LS INTFC 1-7
Function Group A
G301 75
613C
P101-P114
G302 150
G303 30 to 655
G304 75
1249C
G305 150
G306 30 to 440
ED-8C724-30, G1 Shelf
TX and RX: LS INTFC 1-7
Function group B
G307 75
613C
P115-P128
G308 150
G309 30 to 655
G310 75
1249C
G311 150
G312 30 to 440
ED-8C724-30, G1 Shelf
TX and RX: LS INTFC 1-7
Function Group C
G313 75
613C
P129-P142
G314 150
G315 30 to 655
G316 75
1249C
G317 150
G318 30 to 440
