6-18
Issue 9 October 1998
363-206-204
Release 7 Installation Tests
Cross-Connect Procedure
1. Use Office Records or fill in Table 6-2 (for DS1 service) and enter cross-
connections.
NOTE
:
If at any point a ‘?’ or <Return> is entered a menu will prompt you for fur-
ther information.
2. Enter a DS1 pass-through as follows:
ent-crs-vt1:m-1-1-1,m-1-1-1:cct=twoway:y;
3. Enter a DS3 pass-through as follows:
ent-crs-sts1:m-1,m-1:cct=twoway:y;
NOTE
:
In Release 7 cross-connects can be entered in groups using the ‘all’ option.
4. Enter an end DS1 cross-connect as follows:
ent-crs-vt1:m-1-1-1,a-1-1:cct=twoway:y;
5. Enter an end DS3/EC-1 cross-connect as follows:
ent-crs-sts1:m-1,a:cct=twoway:y;
6. Enter a drop and continue DS1 cross-connect as follows:
1. At the first drop and continue node enter:
ent-crs-vt1:m-1-1-1,a-1-1:cct=dc,ring=m1:y;
The parameter ring defines the direction of the continued sig-
nal. Where the traffic must be continued on the ring transmit-
ting to the neighboring drop and continue node. See Note
Below.
Ring
m1
is the ring that is received on the main-1 OLIU and
is transmitted on the main-2 OLIU.
Ring
m2
is the ring that is received on the main-2 OLIU and
is transmitted on the main-1 OLIU.
For VT1.5 cross-connections, once the first VT drop and con-
tinue cross-connection defines the ring direction, all other VT
drop and continue cross-connections at that node are forced
to use that ring rotation.
2. At the second drop and continue node enter:
ent-crs-vt1:m-1-1-1,a-1-1:cct=dc,ring=m2:y;
7. Enter a drop and continue DS3/EC-1 cross-connect as follows:
To Next Page
