Page #388 background image
9-22
Issue 9 October 1998
363-206-204
Release 13 (TARP) Installation Tests
Final Operations
Procedure
1. Verify that all test signals and loopbacks from the DDM-2000 OC-3 have
been removed.
2. Press the UPD pushbutton on the SYSCTL.
3. Verify that the system is configured for normal operation and that no alarms
are present
4. If alarms are present, refer to the "Troubleshooting" section of this manual.
5. Connect the office alarm cables if they have been disconnected.
Table 9-1. Cross-Connections for DSX-1 Testing
Function Group A Function Group B Function Group C
m-1-1-1,a-1-1
m-1-1-2,a-1-2
m-1-1-3,a-1-3
m-1-1-4,a-1-4
m-2-1-1,b-1-1
m-2-1-2,b-1-2
m-2-1-3,b-1-3
m-2-1-4,b-1-4
m-3-1-1,c-1-1
m-3-1-2,c-1-2
m-3-1-3,c-1-3
m-3-1-4,c-1-4
m-1-2-1,a-2-1
m-1-2-2,a-2-2
m-1-2-3,a-2-3
m-1-2-4,a-2-4
m-2-2-1,b-2-1
m-2-2-2,b-2-2
m-2-2-3,b-2-3
m-2-2-4,b-2-4
m-3-2-1,c-2-1
m-3-2-2,c-2-2
m-3-2-3,c-2-3
m-3-2-4,c-2-4
m-1-3-1,a-3-1
m-1-3-2,a-3-2
m-1-3-3,a-3-3
m-1-3-4,a-3-4
m-2-3-1,b-3-1
m-2-3-2,b-3-2
m-2-3-3,b-3-3
m-2-3-4,b-3-4
m-3-3-1,c-3-1
m-3-3-2,c-3-2
m-3-3-3,c-3-3
m-3-3-4,c-3-4
m-1-4-1,a-4-1
m-1-4-2,a-4-2
m-1-4-3,a-4-3
m-1-4-4,a-4-4
m-2-4-1,b-4-1
m-2-4-2,b-4-2
m-2-4-3,b-4-3
m-2-4-4,b-4-4
m-3-4-1,c-4-1
m-3-4-2,c-4-2
m-3-4-3,c-4-3
m-3-4-4,c-4-4
m-1-5-1,a-5-1
m-1-5-2,a-5-2
m-1-5-3,a-5-3
m-1-5-4,a-5-4
m-2-5-1,b-5-1
m-2-5-2,b-5-2
m-2-5-3,b-5-3
m-2-5-4,b-5-4
m-3-5-1,c-5-1
m-3-5-2,c-5-2
m-3-5-3,c-5-3
m-3-5-4,c-5-4
m-1-6-1,a-6-1
m-1-6-2,a-6-2
m-1-6-3,a-6-3
m-1-6-4,a-6-4
m-2-6-1,b-6-1
m-2-6-2,b-6-2
m-2-6-3,b-6-3
m-2-6-4,b-6-4
m-3-6-1,c-6-1
m-3-6-2,c-6-2
m-3-6-3,c-6-3
m-3-6-4,c-6-4
m-1-7-1,a-7-1
m-1-7-2,a-7-2
m-1-7-3,a-7-3
m-1-7-4,a-7-4
m-2-7-1,b-7-1
m-2-7-2,b-7-2
m-2-7-3,b-7-3
m-2-7-4,b-7-4
m-3-7-1,c-7-1
m-3-7-2,c-7-2
m-3-7-3,c-7-3
m-3-7-4,c-7-4
