Lucent Technologies DDM-2000 OC-3 Installation Manual

1-6
Issue 9 October 1998
363-206-204
Introduction
Table 1-1. Miscellaneous Equipment
Item Equipment Code or Commercial Code Comcode
Network Bay Frame
(Front or Rear Access-7 ft.)
ED-8C500-50, G1 -
Network Bay Frame
(Rear Access Only-7 ft.)
ED-8C501-50, G1 -
Stile Cover Assemblies
*
*. Two front stile cover assemblies and six brackets form a
hardware package that provides a flush-look appearance for
DDM-2000 OC-3 when mounted in a 7-foot network bay frame.
846108843
Stile Cover Brackets* 846170017
DDM-2000 OC-3 Shelf Assembly ED-8C724-30, G4 -
Heat Baffle Assembly ED-8C733-30, G1 -
Fan Shelf Assembly
†
†. Prior to G7 Fan Shelf Assemblies G2 were used.
ED-8C733-30, G7 -
DDM-2000 Cable Assemblies ED-8C724-20, -21 ED8C727-20 -
Coaxial Cable 734A, 735A, 1735006A or Equivalent -
Mini-Coax Cable KS-19224, L2 or Equivalent -
Connector 219N Connector for splicing
KS-19224, L2 Mini-Coax to 734A Coax
105643381
963T-16 Connector 105772818
963PH Contact For 963T Connector 845381235
Bracket 4.82" for ED-8C500 Frame 846592913
Bracket 5.94" for ED-8C500 Frame 846593002
Bracket 2.00" for ED-8C501 Frame 846600229
Bracket 3.82" for ED-8C501 Frame 846592905
PANDUIT
‡
Cable Channel for
ED-8C500 Frame (Rear)
E1.5X.75LG78.0-A
PANDUIT
Cable Channel for
ED-8C500 Frame (Front)
or ED-8C501
E1.5X.75LG78.0
PANDUIT
Cover C1.5LG78.0
User Panel Fuses (5 Amp, Qty. 5) 406203976
