8-16
Issue 9 October 1998
363-206-204
Releases 9 and 11 Installation Tests
/* Network Map for Site1NE1
===========================================================
System Name Comm. Product NE Alarm
(TID) Status Type Type Group
===========================================================
Site1NE1 DDM-OC3 DSNE 255
Site2NE1 DDM-OC3 255
Site3NE1 DDM-OC3 255
Site4NE1 DDM-OC3 255
*/
3. To obtain a neighbor map to verify fiber connections to shelves directly con-
nected to Site1NE1 and which OLIU they are connected through, at
Site1NE1 issue the command
rtrv-map-net;
Using Figure 8-1 (or an adapted version to match your ring) at Site1NE1,
verify the following:
/* Neighbor Map for Site1NE1
========================================================
System Name Connected Comm. Product
(TID) Through Status Type
==========================================================
Site1NE1 DDM-OC3
Site2NE1 main-1 DDM-OC3
Site4NE1 main-2 DDM-OC3
*/
4. Continue around the ring verifying that the Neighbor Map "connected
through" indications at each node match the indicated fiber connections of
Figure 8-1 (or your individual map). If not, correct the fiber connections.
5. A Network Map containing all nodes in the network should be obtainable
from any node in the ring.
Test Fiber Connections
1. Alarms associated with fiber disconnects shall be tested. The following test
should be performed at each site. Refer to Figure 8-1.
1. At Site1NE1 disconnect OLIU Main-1 Out. Use the
‘rtrv-alm’
command to check for the following alarm (other alarms may exist)
to verify proper fiber connection:
ne-acty main-1 ------------- inc.OC3 FERF
