Lucent Technologies DDM-2000 OC-3 Installation Manual

3-34
Issue 9 October 1998
363-206-204
Equipment and Front Access Cable Installation
Note
:
Some cables may be manufactured using wires following old color-code standards
Table 3-10. Color Code Cross Reference Connections
Number
Color Paired With
Old New Old New
1C or 26C
2C or 27C
3C or 28C
4C or 29C
5C or 30C
BL1W
O1W
G1W
BR1W
S1W
W-BL
W-O
W-G
W-BR
W-S
BL2W
O2W
G2W
BR2W
S2W
BL-W
O-W
G-W
BR-W
S-W
6C or 31C
7C or 32C
8C or 33C
9C or 34C
10C or 35C
BL1R
O1R
G1R
BR1R
S1R
R-BL
R-O
R-G
R-BR
R-S
BL2R
O2R
G2R
BR2R
S2R
BL-R
O-R
G-R
BR-R
S-R
11C or 36C
12C or 37C
13C or 38C
14C or 39C
15C or 40C
BL1BK
O1BK
G1BK
BR1BK
S1BK
BK-BL
BK-O
BK-G
BK-BR
BK-S
BL2BK
O2BK
G2BK
BR2BK
S2BK
BL-BK
O-BK
G-BK
BR-BK
S-BK
16C or 41C
17C or 42C
18C or 43C
19C or 44C
20C or 45C
BL1Y
O1Y
G1Y
BR1Y
S1Y
Y- B L
Y- O
Y- G
Y- B R
Y- S
BL2Y
O2Y
G2Y
BR2Y
S2Y
BL-Y
O-Y
G-Y
BR-Y
S-Y
21C or 46C
22C or 47C
23C or 48C
24C or 49C
25C or 50C
BL1V
O1V
G1V
BR1V
S1V
V-BL
V-O
V-G
V-BR
V-S
BL2V
O2V
G2V
BR2V
S2V
BL-V
O-V
G-V
BR-V
S-V
