Issue 9 October 1998
4
-1
Lucent Technologies
4
Powering, Verification, and Circuit
Pack Installation
Overview
This section provides information for verifying that the shelf is being supplied with
the proper power and provides instructions for circuit pack option settings and
installation. Detailed information on the function of each circuit pack is contained
in 363-206-202,
DDM-2000 OC-3 Multiplexer User/Service Manual
(Through
Release 7), 363-206-280,
DDM-2000 OC-3 Multiplexer User/Service Manual
(Releases 8 through 11) or 363-206-285,
DDM-2000 OC-3 Multiplexer User/
Service Manual
(Release 13), current issue.
Release 6, 7, 8, 9, 11 and 13 Software Download
The software download procedure mentioned in this section is required for
shelves equipped with Releases 6 and 7 (BBG5 SYSCTL and BBG7 OHCTL)
circuit packs or for Releases 8, 9, 11 and 13 (BBG8 SYSCTL and BBG9 or
BBG10 OHCTL) circuit packs. The SYSCTL and OHCTL circuit packs are shipped
from the factory without the software. A software package containing the
necessary computer diskettes and a software release description document
should be provided with the circuit packs.
NOTE
:
Types of circuit packs available and quantities per shelf are located in Table
4-1.
Software download requires an
MS-DOS
*
compatible personal computer (PC) and
an EIA-232 interface cable for connecting the PC to the connector on the faceplate
of the shelf’s user panel.
*. Registered trademark of Microsoft Corporation.
