363-206-204
Equipment and Front Access Cable Installation
Issue 9 October 1998
3-25
Note
:
The description includes the cable type in parentheses.
1400016A type cable is 26 gauge.
608C type cable is 22 gauge (maximum length is 655 feet).
1249C type cable is 26 gauge (maximum length is 440 feet).
* Filtered DS1 Cable Assemblies are for use when using less than 30 feet.
** These are the interbay DS1 cables. Each of these groups will accommodate one function
group only.
*** The length of groups 433 and 436 is specified by the customer.
Table 3-1. Front Access DS1 Cable Assemblies
Description
(Note)
ED-8C724-21
Group
Cable Length
One Cable
Connector
Other
Connector
Cable from Backplane
to Front of Shelf
Function Group A
(1400016A)
401 4 ft. 8 in. J101-J104 J1A
402 J105-J107 J2A
403 J108-J111 J3A
404 J112-J114 J4A
Cable from Backplane
to Front of Shelf
Function Group B
(1400016A)
405 4 ft.11 in. J115-J118 J1B
406 J119-J121 J2B
407 J122-J125 J3B
408 J126-J128 J4B
Cable from Backplane
to Front of Shelf
Function Group C
(1400016A)
409 4 ft.11 in J129-J132 J1C
410 J133-J135 J2C
411 J136-J139 J3C
412 J140-J142 J4C
From Front of Shelf * 25 ft. P1(), P2()
P2(), P3()
Wire Wrap
From Front of Shelf
to DSX
(608C)**
431 75 ft.
P1(), P2()
P3(), P4()
Wire Wrap
432 150 ft.
433*** 30 ft. to 655 ft.
From Front of Shelf
to DSX
(1249C)**
434 75 ft.
P1(), P2()
P3(), P4()
Wire Wrap
435 150 ft.
436*** 30 ft. to 655 ft.
To Next Page
