Lucent Technologies DDM-2000 OC-3 - Figure 5-1. Installation Test Connections

363-206-204
Release 6 Installation Tests
Issue 9 October 1998
5-21
Figure 5-1. Installation Test Connections
Local Equipment Test
DDM-2000
OLIU IN
OLIU OUT
(test-auto:md=dsx)
Local Wiring Cross-Connect Test
(test-auto:md=local)
OC-3
DDM-2000
DDM-2000
(test-auto:md=system)
End-to-End System Test
DSX-1/DSX-3
DDM-2000
OLIU IN
OLIU OUT
