2-48
Issue 9 October 1998
363-206-204
Equipment and Rear Access Cable Installation
Table 2-19. IAO LAN Connector Pin Identification - Shelf End (P50)
Note: Pins 3, 4, 5, 8 and 9 are not used.
Table 2-18. Universal Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Ty pe
Label
Color
0 dB A3070 106795354
ST
®
None
5 dB A3070B 106795362
ST
®
Blue
10 dB A3070D 106795370
ST
®
Black
15 dB A3070F 106795362
ST
®
Green
20 db A3070H 106795362
ST
®
Red
0 dB A3080 106795404 FC/PC None
5 dB A3080B 106795412 FC/PC Blue
10 dB A3080D 106795420 FC/PC Black
15 dB A3080F 106795438 FC/PC Green
20 db A3080H 106795446 FC/PC Red
0 dB A3060 106708951 SC None
5 dB A3060B 106708969 SC Blue
10 dB A3060D 106708977 SC Black
15 dB A3060F 106708985 SC Green
20 db A3060H 106708993 SC Red
Pin No. Color Function
1 White on Black RQ3P
2 White on Orange XQ3P
6 Black on White RQ3N
7 Orange on White XQ3N
To Next Page
