8-8
Issue 9 October 1998
363-206-204
Releases 9 and 11 Installation Tests
NOTE
:
After cross-connections are entered use
init-sys:all
; with extreme
caution as it erases all cross-connects.
5. When initialization completes, repeat steps 2 and 3 to log back into the
shelf.
6. An AGNE alarm will exist upon completion of the initialization. To extinguish
this alarm, set the AGNE to yes by using the
set-ne
(SET-NETWORK
ELEMENT) command.
7. To change the TID, which is the name of the shelf, issue the command
set-ne
. When prompted with TID= enter the desired TID consisting of up
to 20 alphanumeric characters.
8. To change the number of lines displayed at a time (default = 24), issue the
command
set-link
(SET-LINK). Respond to the page length prompt (pg)
with the desired number of lines, between 3 and 150.
9. To change the time delay for alarms to be displayed or cleared, issue the
command
set-attr-alm
(SET-ATTRIBUTE ALARM). To eliminate any
alarm delay or clear delay, respond to the prompts with 0.
10. To change the time and date displayed, issue the command
set-date
(SET-DATE). Respond to the date and time prompts.
LED Test
Description
This test verifies proper operation of all the LEDs on the DDM-2000 OC-3 shelf.
Operation of all the LEDs is necessary to assist in trouble isolation.
If there are any LED failures, determine if the problem is with the circuit pack or
shelf and replace the faulty unit.
If the shelf is not fully equipped, move circuit packs around and repeat the test in
all circuit pack positions.
Procedure
Issue the command
test-led;
.
The DDM-2000 OC-3 will respond with
In Progress . . . .
for the duration of the test and will issue a prompt CMPLD when the test has
completed. All LEDs on the shelf under test should light for 10 seconds, then
To Next Page
