363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-41
Notes
:
1. Located on the CA1 portion of the Group 371 or 372 cable.
2. Located on the CA2 portion of the Group 371 or 372 cable.
Notes
:
1. The SYSCTL circuit pack reports office alarms.
2. The office alarm cable is 26 gauge.
3. Some cables may be manufactured using wires following old color code standards. A
color code cross-reference is located in Table 2-16.
Table 2-7. Power Connections
Name Design. Conn. Term Color
-48 V (A)
RTN (A)
BAT A
BAT A RTN
J1
(Note1)
1
2
R
BK
-48 V (B)
RTN (B)
BAT B
BAT B RTN
J2
(Note2)
1
2
G
W
Table 2-8. Office Alarm Connections
Name Design Conn. Term Color
Minor Alarm Visible
Minor Alarm Visible Return
Minor Alarm Audible
Minor Alarm Audible Return
MNV
MNVR
MN
MNR
J56 1
2
3
4
BL-W
W-BL
O-W
W-O
Major Alarm Visible
Major Alarm Visible Return
Major Alarm Audible
Major Alarm Audible Return
MJV
MJVR
MJ
MJR
5
6
7
8
G-W
W-G
BR-W
W-BR
Critical Alarm Visible
Critical Alarm Visible Return
Critical Alarm Audible
Critical Alarm Audible Return
CRV
CRVR
CR
CRR
9
10
11
12
S-W
W-S
BL-R
R-BL
To Next Page
