363-206-204
Operational Tests
Issue 9 October 1998
10-21
Notes:
1. The SYSCTL circuit pack reports office alarms.
2. The office alarm cable is 26 gauge.
3. Some cables may be manufactured using wires following old color code standards. A
color code cross-reference is located in Table 3-9.
Table 10-4. Office Alarm Connections
Name Desig. Conn. Term Color
Minor Alarm Visible
Minor Alarm Visible Return
Minor Alarm Audible
Minor Alarm Audible Return
MNV
MNVR
MN
MNR
J56 1
2
3
4
BL-W
W-BL
O-W
W-O
Major Alarm Visible
Major Alarm Visible Return
Major Alarm Audible
Major Alarm Audible Return
MJV
MJVR
MJ
MJR
5
6
7
8
G-W
W-G
BR-W
W-BR
Critical Alarm Visible
Critical Alarm Visible Return
Critical Alarm Audible
Critical Alarm Audible Return
CRV
CRVR
CR
CRR
9
10
11
12
S-W
W-S
BL-R
R-BL
To Next Page
