3-30
Issue 9 October 1998
363-206-204
Equipment and Front Access Cable Installation
Note
:
1. If the office is not equipped for critical alarm display, critical alarm cables should be
multed to major alarm cables.
2. The SYSCTL circuit pack reports office alarms.
3. The office alarm cable is 26 gauge.
4. Some cables may be manufactured using wires following old color-code standards. A
color-code cross-reference is located in Table 3-9.
Table 3-6. Office Alarm Connections
Name Desig. Conn. Term Color
Minor Alarm Visible
Minor Alarm Visible Return
Minor Alarm Audible
Minor Alarm Audible Return
MNV
MNVR
MN
MNR
J56 1
2
3
4
BL-W
W-BL
O-W
W-O
Major Alarm Visible
Major Alarm Visible Return
Major Alarm Audible
Major Alarm Audible Return
MJV
MJVR
MJ
MJR
5
6
7
8
G-W
W-G
BR-W
W-BR
Critical Alarm Visible
Critical Alarm Visible Return
Critical Alarm Audible
Critical Alarm Audible Return
CRV
CRVR
CR
CRR
9
10
11
12
S-W
W-S
BL-R
R-BL
To Next Page
