Lucent Technologies DDM-2000 OC-3 Installation Manual

363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-35
Table 2-2. DS3/EC-1 Cable Assemblies (Cont.)
Notes :
1. All the DS3/EC-1 cable assemblies can be used for any function group. DDM-2000 OC-3
DS3/EC-1 backplane connectors are J38-J43.
2. Cable lengths are specified by the customer for all cables designated as having a (max.)
length. All other cable lengths are fixed.
3. A 1735006A six conductor cable provides three DS3/EC-1 IN and three DS3/EC-1 OUT
cables to accommodate one full function group on the DDM-2000 OC-12 shelf. 734A,
735A, and KS-19224, L2 cables provide one DS3/EC-1 IN cable and one DS3/EC-1 OUT
cable to accommodate a partially equipped function group.
4. All the Group 100 to 136 cables have a BNC KS-23558, L6 connector on one end except
the following: Groups 106 and 107 cables have a BNC KS-23558, L4 connector on one
end. The Group 110 cable has a BNC KS-23626, L5 (right angle) connector on one end.
* For cables going to DACS III-2000 and DACS IV-2000 equipped with a BNC I/O panel,
cable lengths designated as 250 (max.) and 450 (max.) become 500 (max.) and 900
(max.), respectively.
** The Group 126 cable consists of two 734A cables (1-900 feet) with a BNC connector on
one end and no connector on the other end. This group also includes two 13-foot 735A
cables with a 219P connector on one end and a ED-7G001-23, Group 204 cable assem-
bly on the other end. The 735A cable will have to be spliced to the 734A cable per the
219P connector.
*** The Group 136 cable consists of two 734A cables (1-900 feet) with a BNC connector on
one end and no connector on the other end. This group also includes two 13-foot 735A
cables with a 219P connector on one end and a 9821EA or 9821FA connector on the
other end. The 735A cable will have to be spliced to the 734A cable per the 219P con-
nector.
**** All ED8C900 cable groups identified wiith an L (such as G103 F/E 6BB, 6LA) come with
the connector for one end shipped loose; i.e., the cable is terminated only on one end.
