363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-37
DS3/EC-1 Cable Assemblies (Contd)
* The Group 327 cable consists of two 734A cables (250-450 feet) with a BNC connector on
one end and no connector on the other end. This group also includes two 3-foot
KS-19224, L2 cables with a 219N connector on one end and a 9821E or 9821F connec-
tor on the other end. The KS-19224, L2 cable will have to be spliced to the 734A cable.
** The Group 332 cable consists of two 734A cables (250-450 feet) with a BNC connector
on one end and no connector on the other end. This group also includes two 15-foot
KS-19224, L2 cables with a 219N connector on one end and a 846369346 cable assem-
bly on the other end. The KS-19224, L2 cable will have to be spliced to the 734A cable.
To Next Page
