Lucent Technologies DDM-2000 OC-3 Installation Manual

3-8
Issue 9 October 1998
363-206-204
Equipment and Front Access Cable Installation
10. Refer to Table 3-2 and attach the following front access shelf cables, as
required, to the backplane:
■
DS3/EC-1
■
DS1 timing
■
X.25/TL1 interface
■
Order wire
■
Modem
■
Telemetry byte-oriented serial (TBOS)
NOTE
:
TBOS is not available in Release 13 software.
■
Parallel telemetry
NOTE
:
Parallel telemetry is not available in Release 13 software.
■
Office alarms
■
Miscellaneous (environmental) discrete
■
Power.
11. Refer to Table 3-3 and attach the following front access mult cables to the
backplane:
■
DS1 timing mult
■
TBOS mult
NOTE
:
TBOS is not available in Release 13 software.
■
Parallel telemetry mult
NOTE
:
Parallel telemetry is not available in Release 13 software.
■
Office alarms mult.
NOTE
:
A TBOS mult cable (G425) is not attached to J58 if the shelf is the bottom
shelf in the bay.
NOTE
:
The TBOS mult cable (G425) is the only mult cable to be attached to the
top shelf in a bay if, in the future, additional shelves are NOT going to be
installed above.
