Lucent Technologies DDM-2000 OC-3 Installation Manual

5-8
Issue 9 October 1998
363-206-204
Release 6 Installation Tests
AT&T DDM-2000 OC-3 Release a.b.c (before October 1, 1996) or Lucent
Technologies DDM-2000 OC-3 Release a.b.c (October 1, 1996 and later).
This will be in a banner and additional text describing the use restrictions
and proprietary status will follow.
TID date time
/* Active Alarms and Status Report */
<
NOTE
:
Release a.b.c is the software release. TID is the Target Identifier of the
shelf. Date and time are the current system time of the shelf.
Once logged on, the user can only issue commands to the on-line shelf. To
communicate with another shelf in the bay, the user will first have to termi-
nate the session with the current shelf. The session is terminated with the
log;
(LOGOUT) command.
4. Issue the command
init-sys:all
(INITIALIZE-SYSTEM). This com-
mand will configure the DDM-2000 OC-3 with its default parameters.
!
CAUTION:
After cross-connections are entered, use
init-sys:all
with extreme cau-
tion as it erases all cross-connects. Do
not
use this command on a system
that is in service unless you intend to lose service.
5. To change the TID, which is the name of the shelf, issue the command
set-ne
(SET-NETWORK ELEMENT). When prompted with TID= enter
the desired TID consisting of up to 20 alphanumeric characters.
6. To change the number of lines displayed at a time (default = 24), issue the
command
set-link
(SET-LINK). Respond to the page length prompt (pg)
with the desired number of lines, between 3 and 150.
7. To change the time delay for alarms to be displayed or cleared, issue the
command
set-attr-alm
(SET-ATTRIBUTE ALARM). To eliminate any
alarm delay or clear delay, respond to the prompts with 0.
8. To change the time and date displayed, issue the command
set-date
(SET-DATE). Respond to the date and time prompts.
