7-12
Issue 9 October 1998
363-206-204
Release 8 Installation Tests
4. Issue the
set-ne
command to provision each shelf for the following
parameters:
a. Each shelf must have a unique TID (Target Identifier).
b. One shelf (and only one shelf) in the network must be set as the
DSNE (Directory Services Network Element).
c. The Alarm Group must be the same (default=255) for each shelf for
complete alarm reporting throughout the network.
d. One shelf in the network (preferably not the shelf that’s set as the
DSNE) must be set as the AGNE.
e. Site ID and NE (Network Element) combinations must be unique in
each shelf.
f. Shelf numbers must be unique when shelves are located within the
same bay.
g. Cross-Connect Mode (CrsMode) defaults to the default cross-con-
nect map. Set this parameter to manual only if it is desired to deviate
from the default cross-connect map.
h. Set Central Office shelves to CO and Remote Terminal shelves to
RT.
i. Each shelf should be set to a unique TBOS Address.
j. The TBOS Link is for shelves in a CO connected to TBOS. It pre-
vents failure of a single shelf in a bay from causing a TBOS link fail-
ure. The TBOS primary setting assigns a shelf as a backup for a
group of shelves that share the same TBOS link. The secondary
setting provides a secondary backup. Typically, the shelf cabled to
the TBOS is set for PRIMARY and the second shelf in the bay is set
for secondary. All other shelves in the CO bay that are associated
with that TBOS link are set for NORMAL. All shelves in the RT are
set for NO-TBOS.
k. TBOS Remote allows TBOS to be reported over the DCC. In order
for TBOS to be communicated from an RT, TBOS Remote must be
enabled at both the CO and RT shelves.
l. Idle Channel Signal should be set to AIS (default).
5. Issue the
set-fecom:dcc-all:com=enabled;
command to enable far-
end communications in each shelf.
NOTE
:
An inconsistent DCC switch settings alarm will be present while the OLIUs
are optically looped back on themselves.
6. For each optical span, the network elements that terminate on each side of
the optical span must have their OSI "Network Side"/"User Side" parame-
ters set to opposite values. Issue the
rtrv-fecom
; command at each
