ELECTRICAL SYSTEM MLC650 SERVICE/MAINTENANCE MANUAL
3-50
Published 09-09-16, Control # 229-09
PC1-9 No Connection
PC1-10 CAN1_H CAN Bus C—High Not Applicable
PC1-11
+U
B
Supply Power for Control Module Outputs
24 V
DC
PC1-12
+U
E
Control Module Battery Power
24 V
DC
PC1-13 ID03 VPC-MAX Tray Beam Connected
0V
DC
Not Installed, 24 V
DC
Installed
PC1-14 ID04 Not Used—For Possible Future Expansion
0V
DC
PC1-15 ID05 Not Used—For Possible Future Expansion
0V
DC
PC1-16 No Connection
PC1-17 No Connection
PC1-18 IMID2 Module Identifier Input (from ground stud on rotating bed)
0V
DC
PC1-19 CAN1_L CAN Bus C—Low Not Applicable
PC1-20
+U
B
Supply Power for Control Module Outputs
24 V
DC
PC1-21 ID07 Not Used—For Possible Future Expansion
0V
DC
PC1-22 ID08 Not Used—For Possible Future Expansion
0V
DC
PC1-23 ID09 Not Used—For Possible Future Expansion
0V
DC
PC1-24 ID10 Not Used—For Possible Future Expansion
0V
DC
PC1-25 No Connection
PC1-26 No Connection
PC1-27 No Connection
PC1-28 IMID4 Module Identifier Input (from ground stud on rotating bed)
0V
DC
PC1-29 No Connection
PC2-1 ID12 Not Used—For Possible Future Expansion
0V
DC
PC2-2 ID13 Not Used—For Possible Future Expansion
0V
DC
PC2-3 ID14 Not Used—For Possible Future Expansion
0V
DC
PC2-4 No Connection
PC2-5 ODH3A02 VPC Actuator Pin Extend
0V
DC
Off, 24 V
DC
On
PC2-6 ODH3A04
VPC Beam Left Warning Light, VPC Beam Right
Warning Light
0V
DC
Off, 24 V
DC
On
PC2-7 No Connection
PC2-8 ODH3A10 Beam/Foot Upper Pin Retract
0V
DC
Off, 24 V
DC
On
PC2-9 ODH3A12 Beam/Foot Lower Pin Retract
0V
DC
Off, 24 V
DC
On
PC2-10 No Connection
PC2-11
+U
B
Supply Power for Control Module Outputs
24 V
DC
PC2-12 No Connection
PC2-13 IACV19 Not Used—For Possible Future Expansion
0V
DC
PC2-14 IACV20 Not Used—For Possible Future Expansion
0V
DC
Pin I/O Network Function Voltages
