0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 134 / 231
6. Auto Dress Utility Cycle
Stand alone dressing cycle for use after New Wheel setting cycle has been completed.
7. Correction Utilities
For making small corrections to the thread lead
For making small adjustment to the taper of the ground
workpiece thread
For making profile small adjustment to the profile error on
width and radially.
Note: Only available if dressing tool selected as DISC
For making small adjustment to ground workpiece diameter
if any deviation found between actual measured diameter
and the diameter that the machine thinks it is.
For making specific adjustment to points along the
workpiece length when the barrelling function is used
Setting Cycle Access Procedure
1. Set the Orange keyswitch to position 3 on the MCP.
2. Select [AUTO] and [SETUP] mode from the MCP.
3. Select the Setting Cycles menu screen [Custom > Matrix > Main Menu > Setting Cycles]
In general you are expected to at least execute the following setup cycles in the order listed below:
1
st
run the NEW WHEEL cycle
2
nd
run the SET WORK DATUMS cycle
3
rd
run the PITCH-IN cycle
