Matrix 0850 - Machine Configuration

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 22 / 231
Edition: 08/2013
3.3 Machine configuration
1
Direct drive torque motor
workhead (C axis)
2
Traversing worktable (Z axis)
3
Manual Tailstock (standard)
Traversing tailstock (option)
Worktable is fitted with a servo
drive sub-slide (W2 axis).
4
Manual workpiece steady
(standard)
Power steady (option)
5
Water cooled grinding spindle(S1)
6
Wheelhead helix table (A)
7
Dresser spindle (S2)
1
4
5
6
7
Z
2
3
X
A
C
W2
S1
S2
