12 Two-hand auto cycle start (option)
The two-handed cycle start feature located on the control console lets you safely initiate the
automatic cycle and minimal interaction with the machine.
1
LH cycle start button
2
RH cycle start button
If the relevant options have been fitted to the machine then a typical automation sequence would be
as follows:
 Close and lock the access guard door(s)
 Advance the tailstock centre towards the workpiece
 Close the power chuck jaws to clamp the workpiece
 Probe the workpiece
 Grind the workpiece
Then at the end of the cycle the automation sequence would be as follows:
 Open the power chuck jaws
 Retract the tailstock centre
 Open the access guard door(s)
1
1
2
