Matrix 0850 - 4 Technical Data

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 26 / 231
Edition: 08/2013
4 Technical Data
Workpiece
Max Ø admitted
350mm
Max Ø ground - with maximum wheel
350mm
Max Ø ground - with minimum wheel
350mm
Min Ø ground
10mm
Max length supported between centres
800mm
Max thread length ground (between standard centres)
800mm
Max workpiece mass (including workholding)
200kg
Programming
Lead range
0 – 300mm
Pitch shift function
Yes
Pitch correction function
Yes
Lead correction function
Yes
Diameter correction function
Yes
Profile correction function
Yes
Matrix HMI dialog programming
Yes
Machine
Weight (gross)
10,000kg
Floor area
4200 x 5100mm
Grinding Spindle
Max Power
8.8kW
Speed range
500 – 2000rpm
Wheel adaptor interface
Tapered shaft with 70mm locknut
Integral wheel balancing system (SCHMITT)
Standard
Workhead Spindle (C axis) - standard
Servo motor rating
154Nm @ 120rpm
Programmable speed range
1 to 120rpm
Encoder type
Heidenhain /Rotary /Absolute
Positioning resolution
5 arcsec (0.0014°)
Workhead Spindle (C axis) – with power chuck
Servo motor rating
154Nm @ 120rpm
Programmable speed range
1 to 120rpm
Encoder type
Renishaw /Rotary / Incremental
Positioning resolution
5 arcsec (0.0014°)
