Matrix 0850 - Manual Door Operation

To Next Page

To Previous Page

0850/0850-T1 User Manual

Matrix Machine Tool (Coventry) Limited 71 / 231

Edition: 08/2013

11.1 Manual door operation

If the machine is setup to operate without the supported automation features then the front door

must be closed manually by the machine operator prior to starting the cycle.

In this mode of operation the linear actuator assembly remains disabled.
