0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 200 / 231
22.8 General Maintenance Schedule
The recommended maintenance intervals are based on assumptions that the machine is used for 40
hours per week. For more intensive use of the machine, consult Matrix Machine Tool (Coventry) Ltd
for a maintenance schedule.
1. Check/top-up lubrication unit tank (see fig.1 below)
2. Check/top-up helix drum clamping system intensifier glass bowl
lubricator (see fig.2 below)
3. Check spindle coolant unit level
4. Check coolant system level (at sight glass)
5. Check/fix any leaks around the machine
6. Lubricate power chuck at the grease nipple points (if option fitted)
1. Check condition of fume extraction filter
2. Check condition of service cabinet SMC device filter elements
3. Clean the oil cooler filter
4. Clean the spindle cooler filter
5. Clean Electrical Cabinet door fan filter (if non-AC unit)
6. Inject oil (VG68) into tailstock lubrication nipples (see fig.4 below)
1. Inject oil into helix drum slide nipples (see fig.3 below)
2. Clean centrifuge unit drum and empty debris collection bin
3. Empty coolant system debris collection bins
4. Clean the oil filter installed at the inlet point of the cooler unit
5. Drain out any water formed between the tank and the sink of the
coolant system’s oil cooler unit
