0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 56 / 231
9.3.1 Manual Operation Procedure
Two methods are available to manually traverse the tailstock.
Method 1: Jogging the tailstock
1. Select [JOG] mode on the MCP
2. Select [W2] axis
3. Press the [-] key to drive the tailstock forward (advance) or press the [+] key to drive the
tailstock back (retract).
Method 2: Advance/Retract toggle key (optional)
You can rapidly move the tailstock between the advanced and retracted positions by selecting the
toggle key in [JOG] mode.
To advance the tailstock:
1. Select the [JOG] mode at the MCP
2. Select
As the tailstock moves the LED indicator above the key will change to the ‘flashing’ state to inform
you that the tailstock is moving. When the tailstock has stopped advancing the LED indicator changes
from ‘flashing’ to ‘ON’ state.
If the LED indicator continues to flash after the tailstock barrel has stopped advancing then this
means that the barrel has moved to its advanced limit position because either you did not load a
workpiece to the machine or the tailstock has not been correctly positioned such that the dead
centre can support the end of the workpiece.
To retract the tailstock:
3. Select the key again.
As the tailstock moves the LED indicator above the key will change to the ‘flashing’ state to inform
you that the tailstock barrel is moving. When the tailstock has stopped retracting the LED indicator
changes from ‘flashing’ to ‘OFF’ state.
