19.25 Cycle Stop/interrupt
You can stop the active grinding cycle in a number of ways as outlined in the table below which also
details the consequences of the method by which you have chosen to stop the cycle.
Cycle stop action
Is my workpiece
likely to become
scrap?
Do I need to run the
cycle from the
beginning?
Press the Yellow [WHEEL RETRACT] button
NO
YES
Press the Red [EMERGENCY STOP] button
YES
YES
Power-off the machine at main isolator
YES
YES
Press the [RESET] key at the MCP
YES
YES
Select the [BLOCK SKIP] key at the MCP
NO
NO
Should there be a need to interrupt or abort the active grind cycle it is recommended that you select
the [BLOCK SKIP] function at the machine control panel to bring the cycle to a controlled stop.
