8 Powered workpiece support steady (option)
The ROHM SLZV-1540 is a highly repeatable self-centering hydraulically powered workpiece
steady/rest and locates across the vee-and-flat section of the worktable.
1
3x steady arms (shown in retracted position)
Fully retractable arms (1) are a key feature of this steady, leaving the working area free from
unwanted obstruction when loading and unloading workpieces.
Clamping range: Ø12 - Ø40
Working Pressure: 10 – 30 bar
You can adjust the steady arms clamping pressure at the hydraulics power pack (see section 8.3.1)
