Matrix 0850 - Single-Point Diamond Holder (Option)

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 35 / 231
Edition: 08/2013
5.4 Single-point diamond holder (option)
An alternative to the rotary truer system is the single point diamond system primarily used where
wheel profiles demanding small profile radii (<= 0.1mm) are required.
CAUTION
The expanding collet must be removed before you fit the single point mounting
block.
30mm
