Matrix 0850 - Page 204

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 204 / 231
Edition: 08/2013
1
Centrifuge drive motor
5
Oil drain back hose
2
Hinged cover for access to drum
lock lever
6
Cleaned oil exit pipe outlet feeding to
clean oil tank
3
Removable inspection panel
7
Lift pump to transfer oil from main tank
to the centrifuge
4
Debris collection bin on castors
Lift pump flow adjust valve
7
5
6
8
