0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 96 / 231
General machine lights ON/OFF toggle.
C/Z axis gear link ON/OFF toggle.
Press this key to link the C and Z axes together. Z axis jog is not permitted when
the gearbox function is activated. However, when the C axis is jogged the Z axis
will follow according the established C/Z gear ratio used by the active workpiece.
Use this function out-of-cycle when you need to test the relative position of the
grinding wheel to the pre-cut workpiece thread or other inspection.
TAILSTOCK ADVANCE/RETURN (option)
If pneumatic tailstock barrel option fitted:
Press this toggle key to advance or retract the tailstock barrel if th.
If travelling tailstock option fitted:
Press this toggle key if to drive the tailstock to the advance or retracted position.
The indicator above the key illuminates when the tailstock has moved to the
advance position.
PROBE ADVANCE/RETURN (option)
Probe slide advance/retract toggle key.
Press this key to advance or retract the probe slide.
The indicator above the key illuminates when the probe slide has moved to the
advanced position.
