25 - 10
25.2 Preparatory Procedures for Monitoring
25.2.5 Attaching communication unit and connecting cable
25.2.5 Attaching communication unit and connecting cable
Cautions when attaching the communication unit and connecting the cable
Shut off all phases of the GOT power supply before attaching the communication
unit and connecting the cable.
1 How to connect the cable
(1) How to connect the RS-232 cable
(a) For the GT15
(b) For the GT11
1 Connect the RS-232 cable to the RS-232
interface on the GOT.
1 Connect the RS-232 cable to the RS-232
interface on the GOT.
