24 - 6

24.1 System Configuration

24.1.3 Connecting to the MELSERVO-J3 Series

1 System configuration and connection conditions

*1 Connect the connector of the servo amplifier to CN3.

*2 Multi-drop communication (Up to 32 axes can be connected.)

Connection conditions

System Configuration

Number of

GOTs

Communication

Distance

1 RS-232/422

RS-232

RS-422

1 RS-422 30m or less

Communication driver

MELSERVO-J3, J2S/M

RS-422/232 conversion

cable

RS-422 cable 2)

RS-422/232 converter

RS-232 cable 2)

RS-422 cable 3)

MAX30m

4 4

RS-422 cable 3)

RS-422 cable 4)

*2 *2 *2

*1*1*1

RS-422

cable 6)

Distributor

RS-422 cable 5)
