Mitsubishi GOT1000 Series - Connecting to JW-70 CUH, JW-100 CUH or JW-100 CU

11 - 10
11.1 System Configuration
11.1.4 Connecting to JW-70CUH, JW-100CUH or JW-100CU
11.1.4 Connecting to JW-70CUH, JW-100CUH or JW-100CU
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Distance
1
Differs
according to
PLC side
specifications.
SHARP JW
Communication driver
RS-232 cable 1)
1
4
5
RS-422 cable 1)
2
3
6
Link unit
RS-422 cable 3)
2
