4.1 System Configuration
4.1.7 Connecting to motion controller CPU (Q Series)
4.1.7 Connecting to motion controller CPU (Q Series)
A motion controller CPU (Q Series) mounted to the multiple CPU system of the QCPU (Q mode) can be
monitored.
The system configuration, connection conditions and system equipment when connecting the GOT to a
motion controller CPU (Q Series) are the same as the case of the QCPU (Q mode).
( Section 4.1.1 Connecting to QCPU (Q mode))
4.1.8 Connecting to motion controller CPU (A Series)
The system configuration, connection conditions and system equipment when connecting the GOT to a
motion controller CPU (A273UCPU, A273UHCPU (-S3), A373UCPU (-S3)) are the same as the case of the
AnCPU type. ( Section 4.1.5 Connecting to AnCPU type)
The system configuration, connection conditions and system equipment when connecting the GOT to a
motion controller CPU (A171SHCPUN, A172SHCPUN, A173UHCPU (-S1)) are the same as the case of the
AnSCPU type. ( Section 4.1.6 Connecting to AnSCPU type)
4.1.9 Connecting to remote I/O station in MELSECNET/H network system
When the GOT is connected to a remote I/O station in the MELSECNET/H network system, the system
configuration, connection conditions and system equipment is identical with those in the case of QCPU
connection. ( Section 4.1.1 Connecting to QCPU (Q mode))
A/QnA/QCPU,QJ71C24, MELDAS C6*
Communication driver
AJ71C24/UC24
Communication driver
A/QnA/QCPU,QJ71C24, MELDAS C6*
Communication driver
