20 - 6
20.1 System configuration
20.1.3 Connecting to E5ZN
20.1.3 Connecting to E5ZN
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Number of
Temperature
controller
connection
Communi
-cation
Distance
1
RS-232 15m or less
16 (max.) RS-485 500m or less
1 15 (max.) RS-485 500m or less
Communication driver
OMRON
THERMAC/INPANEL NEO
MAX15m
RS-232 cable 2)
MAX500m
RS-485 cable 1)
1
16 (max.)
Interface converter
MAX500m
RS-485 cable 2)
2
15 (max.)
