27 - 42
27.3 CC-Link Connection (Intelligent Device Station)
27.3.1 System Configuration
27.3 CC-Link Connection (Intelligent Device Station)
Connectable CNC is MELDAS C6/C64 series.
Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
27.3.1 System Configuration
1 System configuration and connection conditions
*1 Max. overall cable length and the length between stations vary depending on the cable type to be used and
transmission speed.
For details, refer to the following manuals.
MELDAS C6/C64 CONNECTION AND MAINTENANCE MANUAL BNP-B2255
MELDAS C6/C64 NETWORK MANUAL BNP-B2373
2 System equipment
(1) GOT
Connection conditions
System configuration
Number of GOTs Distance
26 (max.) *1
Image No. Name Model name
CC-Link comunication unit
Intelligent device station
GT15-75J61BT13-Z
CC-Link(ID)
Communication driver
3
2
1
Expansion unit
CC-Link dedicated cable
CC-Link
CC-Link
(Intelligent)
(Intelligent)
