2.1 System Configuration
2.1 System Configuration
Select a system configuration suitable for your application.
(1) Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions
correspond to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
(2) About connection cables
Select a proper connection cable whose length satisfies the distance conditions
according to the connection conditions.
Section 2.4
Communication
Check Sheet
Write down the items selected in this section to the check sheet.
OS selection
• Communication driver: Name of the communication driver
Unit selection
• Communication module: Model name
• Bus extension connector box/Bus connector conversion box: Model name
Write Check
Sheet
To Next Page
