20.4 Temperature Controller Side Setting
20.4.3 Connecting to interface converter (K3SC-10)
20 - 29
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
20.4.3 Connecting to interface converter (K3SC-10)
1 Communication settings
Make the communication settings by operating the DIP switch of the temperature controller.
*1 Make the same setting as that of GOT side.
*2 Set to “Without”
2 Settings by DIP switch
(1) Transmission speed settings
Item Set value
Transmission speed
*1
19200bps, 38400bps
Data length
*1
7 bits, 8 bits
Parity bit
*1
Odd, even, none
Stop bit
*1
1 bit, 2 bits
Master/slave device
RS-232 RS485
Echoback
*2
With, Without
Transmission
speed(bps)
Switch No.
1 2 3
1200 ON OFF OFF
2400 OFF ON OFF
4800 ON ON OFF
9600 OFF OFF OFF
19200 ON OFF ON
38400 OFF ON ON
Terminal block for RS-422/485
communication
Terminal block for RS-232
communication
Front of K3SC-10 body
Inside of K3SC-10 body
(When removing the front cover)
DIP switch
ON
SW
Set these switches.
