2.2 Preparatory Procedures for Monitoring
2.2.5 Attaching communication unit and connecting cable
2 - 37
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION
TO CPU
4
COMPUTER LINK
CONNECTION
5
MELSECNET/10
CONNECTION (PLC TO
PLC NETWORK)
6
CC-Link CONNECTION
(INTELLIGENT DEVICE
STATION)
7
CC-Link CONNECTION
(Via G4)
8
ETHERNET
CONNECTION
2.2.5 Attaching communication unit and connecting cable
Cautions when attaching the communication unit and connecting the cable
Shut off all phases of the GOT power supply before attaching the communication
unit and connecting the cable.
1 Attaching the communication unit
(1) When mounting GT15-75QBUS, GT15-75QBUS2, GT15-75ABUSL, GT15-75ABUS2L
(2) When mounting GT15-QBUS2, GT15-ABUS2
(3) When mounting GT15-QBUS, GT15-ABUS
Bus connection unit
For details on the bus connection unit, refer to the following manual:
GT15 BUS CONNECTION UNIT User's Manual
GT15-QBUS/GT15-QBUS2/GT15-ABUS/GT15-ABUS2
GT15 BUS CONNECTION UNIT User's Manual
1 Attach the bus connection unit to the extension unit
connector on the GOT.
2 Attach the bus connection unit to the extension unit
connector on the GOT.
3 Attach the bus connection unit to the extension unit
connector on the GOT.
