27.2 MELSECNET/10 Connection (PLC To PLC Network)
27.2.4 Checking OS installation on GOT
27 - 25
25
BAR CODE READER CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL FUNCTION
29
FA TRANSPARENT FUNCTION
30
MULTIPLE-GT11 CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
27.2.4 Checking OS installation on GOT
Check if the OS is properly installed or not on the Drive information tab of GT Designer2.
For the operation on the Drive information tab, refer to the following manual.
GT Designer2 Version Basic Operation/Data Transfer Manual
The OS has been installed successfully on the GOT
if the following can be confirmed:
1) Standard monitor OS
2) Communication driver: MELSECNET/10
