15 - 4
15.1 System Configuration
15.1.2 Connecting to GL60S, GL60H, GL70H
15.1.2 Connecting to GL60S, GL60H, GL70H
1 System configuration and connection conditions
Connection conditions
System configuration
No. of GOTs Distance
1
Differs according to
PLC side
specifications.
YASKAWA GL/CP9200(SH/H)/CP9300MS
Communication driver
RS-232 cable 1)
5
MEMOBUS module
3
1
RS-422 cable 1)
6
MEMOBUS module
4
2
