20.2 Connection Cable
20.2 Connection Cable
The RS-232 cable or RS-422 cable used for connecting the GOT to the PLC should be prepared by the user.
The following provides connection diagrams for each cable, connector specifications and other information.
Model name
Connection cable
RS-232 cable
(Refer to Section20.2.1)
RS-422 cable
(Refer to Section20.2.2)
Temperature
controller
E5AN RS-232 cable1), RS-232 cable2) RS-485 cable1), RS-485 cable2)
E5EN RS-232 cable1), RS-232 cable2) RS-485 cable1), RS-485 cable2)
E5CN RS-232 cable2) RS-485 cable1), RS-485 cable2)
E5GN RS-232 cable2) RS-485 cable1), RS-485 cable2)
E5ZN RS-232 cable2) RS-485 cable1), RS-485 cable2)
Interface
converter
K3SC-10 RS-232 cable2) RS-485 cable1)
