21.3 Preparatory Procedures for Monitoring
21.3.2 Checking OS installation on GOT
21.3.2 Checking OS installation on GOT
Check if the OS is properly installed or not on the Drive information tab of GT Designer2.
For the operation on the Drive information tab, refer to the following manual.
GT Designer2 Version Basic Operation/Data Transfer Manual
The OS has been installed successfully on the
G
if the following can be confirmed:
1) Satndard monitor OS
2) Communication driver: YAMATAKE SDC/DM
