2.1.5 Connecting to motion controller CPU (Q Series)
A motion controller CPU (Q Series) mounted to the multiple CPU system of the QCPU (Q mode) can be
monitored.
The system configuration, connection conditions, and system equipment for connection to a motion
controller CPU (Q Series) are the same as those for connection to the QCPU (Q mode).
( Section 2.1.1 Connecting to QCPU (Q mode))
Communication driver
Bus(Q)
