Mitsubishi GOT1000 Series User Manual

27 - 2
27.1 Direct Connection To CPU
27.1.1 System Configuration
27.1 Direct Connection To CPU
Connectable CNC is MELDAS C6/C64 series.
Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
27.1.1 System Configuration
1 System configuration and connection conditions
*1 Connect the connector of the CNC side to TERMINAL.
*2 Connect the connector of the CNC side to SIO.
Connection conditions
System configuration
Number of GOTs
Communic
ation
Distance
1
RS-232 15m or less
RS-422 30.5m or less
A/QnA/QCPU,QJ71C24,
MELDAS C6*
Communication driver
4
RS-232 cable
1
*1
2
GPP
RS232
5
RS-422 cable
3
F311 cable
*2

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
