14 - 6
14.1 System Configuration
14.1.3 Connecting to FP2 or FP2SH
14.1.3 Connecting to FP2 or FP2SH
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Distance
1
3m or less
15m or less
MATSUSHITA
MEWNET-FP
Communication driver
MAX3m
Connect to the tool port.
RS-232 cable
3
1
MAX15m
Connect to the RS232C port.
RS-232 cable 2)
4
1
1
MAX15m
Computer communication unit
2
RS-232 cable 2)
4
